Coax Connector Adapter
Coax Connector Adapter
Couldn't load pickup availability
BNC female adapters for SMA connectors on HTs and other receivers. These adapters include a wide shoulder ring for ease of use and a sturdy connection.
To determine which adapter you need look at the connection on the radio with the antenna removed. If you see a center pin you need a BNC-F to SMA-F adapter. If you see a receiving socket you need a BNC-F to SMA-M adapter.
My FoxSniffer RDF receiver has an SMA-F connector and so requires the BNC-F to SMA-M adapter. The tables below list the connectors for common radios. I've done my best to ensure accuracy of this information and will update or correct the tables as needed. I cannot guarantee 100% accuracy. It's always best to confirm on the radio itself.
Radios with SMA-F Connectors (Use SMA-M Adapter)
Brand |
Models |
| AI6YM | FoxSniffer |
| Alinco | DJ-G7, DJ-V5, and older models |
| BaoFeng | UV-3R |
| Icom | ID-51, ID-52, IC-T10, IC-V86 |
| Kenwood | TH-D75, TH-D74, TH-D72, TH-F6A |
| Radioddity | GD-77, GD-88 |
| Retevis | RT3, RT3S |
| TYT | MD-380, MD-390, MD-UV380, MD-UV390+, TH-UV88 |
| Wouxun | KG-UV9D, KG-UV9D Plus, KG-UV9P and certain KG-UV6D versions |
| Yaesu | FT-60R, FT-70DR, FT-3DR, FT-5DR, VX-3/6/7/8 |
Radios with SMA-M Connectors (Use SMA-F Adapter)
Brand |
Models |
| Alinco | DJ-MD5 series, DJ-500 |
| AnyTone |
AT-D868UV, AT-D878UV, D878UVII+ |
| Baofeng | UV-5R, UV-82, BF-F8HP, UV-9R, and most current models |
| BTECH | UV-5X3, UV-PRO, and most HTs |
| Hytera |
TC-518 and most commercial models |
| Kenwood |
TK-2000/3000 series, most NX-series |
| Quansheng | UV-K5, UV-K6 |
| Radioddity |
GM-30 Plus/Pro, GS-10B |
| Radtel |
RT-470X and most other models |
|
Retevis / Ailunce |
RT5R, HD1, HD2, and most others |
|
TIDRADIO |
TD-H3, TD-H8 |
| Wouxun | KG-805G, KG-905G, KG-935G, KG-Q10H, most other models |
| Yaesu | FT-4XR, FT-4VR, FT-25R, FT-65R |
If the F and M annotation is not clear you may need to ask your parents for details.
